Name: Honeycomb Dehumidifier
Brand: GuangDong Soxi Intelligent Equipment Co., Ltd.

Honeycomb dehumidifiers are also called wheel dehumidifiers. Dehumidifiers can be divided into two categories: private dehumidifiers and industrial dehumidifiers. Traditional dehumidifiers usually consist of a compressor, heat exchanger, fan, water tank, housing, and controller. The principle of operation is as follows. The fan draws moist air into the machine and passes through the heat exchanger. At this time, the water molecules in the air condense into water droplets and the treated dry air is exhausted from the machine. This circulation maintains the humidity in the room at an appropriate level of relative humidity.

Specification Of Honeycomb Dehumidifier

Dehumidification air volume			m3/h	60	80	120	150	200	300	400	500	700	1000
Runner size			mm	Φ150X200H	Φ180X200H	Φ250X200H	Φ250X300H	Φ250X400H	Φ350X300H	Φ350X400H	Φ440X300H	Φ440X400H	Φ550X400H
Dew point			℃	-40~-50
Outlet and return air diameter			Inch	2”	2”	2.5”	2.5”	2.5”	3”	3”	4”	4”	5”
Electric power	Total power		kw	3.58	9.63	5.65	7.9	7.9	10.75	11.55	18.6	23	26.7
	Air circulation blower power		kw	0.4	0.55	0.75	1.5	1.5	2.2	3	5.5	7.5	8.5
	Regenerative heater power		kw	3	4	4.5	6	6	8	8	12	14	16
	Regenerative fan power		kw	0.18	0.2	0.4	0.4	0.4	0.55	0.55	1.1	1.5	2.2
Electric power source specification				380V 50Hz 3P
Cooling water interface			Inch	3/4”	3/4”	3/4”	3/4”	3/4”	1”	1”	1”	1”	1”
Dimensions		Width	mm	600	600	650	650	650	800	800	900	900	1000
		Depth	mm	700	700	850	900	900	1100	1100	1100	1200	1300
		Height	mm	1450	1450	1550	1760	1760	1800	1800	2050	2050	2050

Features Of Honeycomb Dehumidifier

Stably provide -40℃~-50℃ dew point
The honeycomb wheel type dehumidification method is suitable for large-scale dryers
Optional for multiple dryers
Equipped with communication interface, can undertake future industry 4.0
